Reyee RG-EST350 V2 5GHz Dual-stream802.11ac Wireless Bridge
Rp3.221.220
Deskripsi
|
Model |
RG-EST350 V2 / RG-EST350 |
|
Hardware Specifications |
|
| RAM/ Flash | 512 MB/8 MB |
| Radio | Dual-stream single-band 2×2 |
| Operating Band | 802.11a/n/ac: 5.150～5 .350GHz, 5.470~5.725GHz , 5.725～5 .850GHz (country specific) |
| Antenna | Directional antennas, 15 dBi |
| Polarization | Horizontal: 31°, Vertical: 14° |
| Bridging Distance | 5 KM (recommended) |
| Spatial Streams | Two streams |
| Maximum Throughput | Up to 867 Mbps at 5 GHz |
| Max. Transmit Power | ≤400 Mw(26 dBm) (adjustable) |
|
Dimensions |
230 mm(D)×132 mm(W)×48 mm(H) (Dimensions per device) |
| (Same size for the recorder-end and camera-end, | |
| H: height of the device edge excluding the mounting kits) | |
| Weight | 0.5 kg |
|
Ports |
Two 10/100/1000Base-T Ethernet ports, supports 24 VDC non-standard PoE power supply
One DC port, supports 12 VDC power supply |
| Hardware Button | 1 reset button |
|
Status Indicators |
System indicator: 1
Port indicator: 2 Bridge signal strength indicators: 3 |
| Power Supply | Support 12 VDC power supply and 24 VDC non-standard PoE power supply |
| Power Consumption | ≤10W |
|
Environment |
Operating temperature: -30°C to 65°C (-22°F ~ 149°F) |
| Storage temperature: -40°C to 85°C (-40°F ~ 185°F) | |
| Operating humidity: 5% to 95% (noncondensing) | |
| Storage humidity: 5% to 95% (noncondensing) | |
| Installation | Wall-mounted/ Pole-mounted (hose clamp is provided) |
| IP Rating | IP54 |
| Lightning Protection | 4 KV |
| Radio Standard | EN300 328, EN301 893 |
|
Software Features |
|
|
Automatic Bridging |
Support
The recorder-end and camera-end are automatically paired for bridging by default |
| One-to-many Bridging | One-to-three bridging is recommended for the wireless coverage scope at an |
| Device Configuration
and Management |
angle of 31° to the horizontal.
Support App/Web configuration |
|
QR Code Login |
Users can log in to the device configuration interface by scanning the QR code
of the device using the app |
| Self-healing | Automatic restart upon equipment failure |
| Automatic Channel
Adjustment |
Automatically adjust the channel upon power-on |
