Rujie RG-AP880(TR) Wi-Fi 6 Tri-Radio 10 Gbps High-density Indoor AP

Radio design

Tri-radio design, up to a total of ten spatial streams

Radio1: 2.4 GHz, two spatial streams: 2×2 MIMO

Radio2: 5 GHz, four spatial streams: 4×4 MU-MIMO

Radio3: 2.4 GHz/5 GHz, four spatial streams: 4×4 MU-MIMO

Operating frequencies

Radio1: 802.11b/g/n, 2.400 GHz to 2.483 GHz

Radio2: 802.11a/n/ac/ax, 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz

Radio3:

802.11b/g/n/ax: 2.400 GHz to 2.483 GHz

802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz

Note: The operating radio is country-specific.

Data rate

Radio 1: 2.4 GHz, 400 Mbps

Radio 2: 5 GHz, 4.8 Gbps

Radio 3:

2.4 GHz, 1.1 Gbps,

5 GHz, 4.8 Gbps

Combined:

2.4 GHz + 5 GHz + 2.4 GHz, 6.3 Gbps

2.4 GHz + 5 GHz + 5 GHz, 10 Gbps

Antenna type

Built-in smart antennas

Antenna gain

2.4 GHz: 3 dBi

5 GHz: 3 dBi

Max. transmit power

20 dBm

Note: The transmit power varies based on the regulations in different countries and regions.

Power increment

1 dBm

Modulation

OFDM: BPSK @ 6/9 Mbps, QPSK @ 12/18 Mbps, 16-QAM @ 24 Mbps, and 64-QAM @ 48/54 Mbps

DSSS: DBPSK @ 1 Mbps, DQPSK @ 2Mbps, and CCK @ 5.5/11 Mbps

MIMO-OFDM: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, and 1024-QAM

OFDMA

Receive sensitivity

802.11b: –96 dBm (1 Mbps), –93 dBm (5 Mbps), and –89 dBm (11 Mbps)

802.11a/g: –91 dBm (6 Mbps), –85 dBm (24 Mbps), –80 dBm (36 Mbps), and –74 dBm (54 Mbps)

802.11n: –90 dBm @ MCS0, –70 dBm @ MCS7, –89 dBm @ MCS8, –68 dBm @ MCS15

802.11ac: HT20: –88 dBm (MCS0) and –63 dBm (MCS9)

802.11ac: HT40: –85 dBm (MCS0) and –60 dBm (MCS9)

802.11ac: HT80: –82 dBm (MCS0) and –57 dBm (MCS9)

802.11ax: HE80: –82 dBm (MCS0), –57 dBm (MCS9), and –52 dBm (MCS11)

Bluetooth

Supported

USB port

USB 2.0

Fixed service port

Uplink ports:

Two 100/1000/2500/5000Base-T electrical ports with auto-negotiation, supporting IEEE 802.3af/af/bt-compliant PoE.

Downlink port:

One 10/100/1000Base-T Ethernet port with auto-negotiation, supplying power (12 V/0.25 A) to IoT modules.

Fixed management port

One RJ45 console port

Status LED

One system status LED

Button

One Reset button

Input power supply

• 48 V DC/1.5 A power supply
• PoE/PoE+/PoE++ power supply, IEEE 802.3af/at/bt-compliant

Note: If the AP is powered by IEEE 802.3af-compliant PoE power supply, only the CPU works and other modules do not work. If the AP is powered by IEEE 802.3at-compliant PoE power supply, Radio 3 does not work and the AP does not serve as PSE to supply power to external devices.

External power supply

Supported (supplying power to Ruijie IoT modules, 12 V/0.25 A output)

Max. power consumption

40 W

Power redundancy

Supported when the AP is powered by dual PoE++ power supplies or dual PoE+ power supplies
